KAPAL DIVING 11 METER
DIVING BOAT 11 METER
PEMESANAN HUB : WA : 081 33333 7303
MATERIAL OPTION
| UKURAN UTAMA |
| PANJANG [Length] | : | 11.00 | meter |
| LEBAR [Beam] | : | 02.80 | meter |
| TINGGI LAMBUNG [Height] | : | 01.20 | meter |
| SARAT [Draught] | : | 00.40 | meter |
| MESIN [Engine] | : | |
| TAHUN [Years] | : | 2025 |
| MATERIAL KAPAL DIVING 11 METER FIBERGLASS |
| Bottom – 10 Layer Kombinasi Mat300+WR600 |
| Side – 8 Layer Kombinasi Mat300+WR600 |
| Deck – 5 Layer Kombinasi Mat300+WR600 |
| Frame Profile Fiberglass |
| MATERIAL KAPAL DIVING 11 METER ALUMINUM |
| Bottom Plate – 5 mm – Aluminium Marine 5083 H116 |
| Side Plate – 5 mm – Aluminium Marine 5083 H116 |
| Deck Plate – 4 mm – Aluminium Bordes |
| Cabin Plate – 4 mm – Aluminium Marine 5083 H116 |
| Top Cabin Plate – 3 mm – Aluminium Marine 5083 H116 |
| A | PERLENGKAPAN DECK |
| 1 | Bow Railing ss.304 dia 1″ | 1 | Set |
| 2 | Railing Atas ss.304 dia 1″ | 1 | Bh |
| 3 | Tiang Bendera | 1 | Bh |
| 4 | Hatch Lubang Jangkar | 1 | Bh |
| B | PERLENGKAPAN TAMBAT & LABUH |
| 1 | Cleat Pengikat Tali Jangkar | 1 | Bh |
| 2 | Cleat Pengikat Tali Tambat | 4 | Bh |
| C | INTERIOR & EXTERIOR |
| 1 | Kursi pilot | 1 | Bh |
| 2 | Kursi Navigator | 1 | Bh |
| 3 | Kaca Depan Tempered 5mm | 1 | Set |
| 4 | Kaca Samping Tempered 5 mm | 1 | Set |
| 5 | Toilet + Shower | 1 | Set |
| 6 | Diving Rack / Hole | 1 | Set |
| D | SYSTEM PIPA DAN POMPA |
| 1 | Sistem Pengisian dan Distribusi BBm | 1 | Set |
| 2 | Sistem Pengisian dan Distribusi Air | 1 | Set |
| 3 | Bilge pump 2000 GPH | 1 | Bh |
| E | LAMPU NAVIGASI DAN PENERANGAN |
| 1 | Lampu Cabin | 4 | Set |
| 2 | Lampu Deck Belakang | 1 | Set |
| 3 | Lampu Sorot Depan | 1 | Set |
| 4 | Lampu Navigasi Merah Hijau , Putih | 1 | Set |
| F | KELISTRIKAN |
| 1 | Wiring System | 1 | Lot |
| 2 | Switch Panel | 2 | Bh |
| 3 | Battere Switch | 1 | Bh |
| 4 | Horn Trumpet | 1 | Bh |
| 5 | Wiper | 1 | Bh |
| G | ALAT KOMUNIKASI & NAVIGASI |
| 1 | GPS Garmin 65SV | 1 | Bh |
| 2 | Radio VHF | 1 | Bh |
| H | TANK |
| 1 | Tanki BBM Cap.400 Liter | 1 | Bh |
| 2 | Tangki Air 100 Liter | 1 | Bh |
| I | STEERING SYSTEM [ SISTEM KEMUDI ] |
| 1 | Hydraulic Steering System | 1 | Set |
| J | ALAT KESELAMATAN [SAFETY & APPARATUS] |
| | NO | | |
| | | | |
| TERM & CONDITION | | TERM OF PAYMENT |
| 1 | Harga Validasi 30 hari | 1 | 30% | DP |
| 2 | Harga Tidak Termasuk Pajak | 2 | 30% | Release Mould [Fiber] , Part Ready Assembly [Alloy] |
| | | 3 | 30% | Start Install Accessories ( Kaca , Pintu , dll) |
| | | 4 | 10% | Before Delivery |
| | | 5 | | |
| BUILDING TIME : 5 Bulan [ Months ] |
| WARRANTY : 6 MONTHS – Max 5% dari Harga Body |
| HARGA KAPAL DIVING 11 METER – BAHAN FIBERGLASS – TANPA MESIN |
| Call – WA 081333337303 |
| HARGA KAPAL DIVING 11 METER – BAHAN ALUMINIUM – TANPA MESIN |
| Call – WA 081333337303 |
